HMI

The key features of our HMIs

The MOONS’ ATP5000 series includes network industrial HMIs designed to provide a modern, intuitive operator interface that can be easily integrated into automation systems. Thanks to the high-resolution, high-brightness 16:9 LCD display, compact hardware configuration, and integrated communication interfaces, ATP5000 HMIs are an effective solution for visualizing, monitoring, and managing machine functions.

An HMI interface designed for connected machines and advanced automation systems

ATP5000 series HMIs are designed to simplify interaction between operator and machine, offering a clear, responsive, and easily configurable visualization platform.

The combination of a high-brightness display, 1 GHz Cortex-A7 processor, integrated memory, and a wide range of communication ports allows ATP5000 HMIs to be used in industrial applications where control, diagnostics, recipe management, parameter monitoring, and communication with PLCs or field devices are required.

Why choose the ATP5000 series

1. High-readability industrial display

TFT LCD display in 16:9 format, with 1024 × 600 resolution, 24-bit colors, and LED backlighting. The series is available in 7” and 10.1” formats, with brightness levels of 350 cd/m² and 400 cd/m² respectively.

2. Compact and high-performance hardware

La piattaforma integra un processore 1 GHz dual-core Cortex-A7, memoria 256 MB DDR3 e storage 4 GB eMMC, offrendo una configurazione adatta alla gestione delle principali funzioni di visualizzazione e controllo macchina.

The platform integrates a 1 GHz dual-core Cortex-A7 processor, 256 MB DDR3 memory, and 4 GB eMMC storage, offering a configuration suitable for managing the main machine visualization and control functions.

3. Configurazione semplice con ATP Studio

ATP Studio software supports mainstream PLCs and drivers, OPC UA and Modbus RTU/TCP protocols, graphical programming, recipe management, string tables, and macros.

4. Extensive integrated connectivity

ATP5000 HMIs support serial, Ethernet, USB, and Type-C communication. The product specifications include RS232 / RS485 / RS422 ports, 10/100M Ethernet, USB Type-A, and Type-C OTG interface.
